- Triac dimming, AC40V-220V dimming input.
- Applies to triac front/back edge dimmers and dimming system.
- Single channel PWM constant voltage output, output current max. 15 A.
- Digital PWM dimming, logarithmic dimming curve.
- Over current protection, short circuit protection, over temperature protection.
- Connect external AC push button switch for on/off and dimming function.
Technical specifications
- Input voltage: 12-48VDC;
- Output voltage: 12-48VDC;
- Output current: 1CH, 15A;
- Output power: 180W/360W/540W/720W (12V/24V/36V/48V);
- Input signal: 40-220VAC + AC Push-Dim;
- Dimming range: 0-100%;
- Working temperature: -30~+55ºС;
- Degree of dust and moisture protection: IP20;
- Warranty: 5 year.
