Motion sensor dimming controller 5-24VDC 1CH*3A PIR DEYA EV-R

• Operation using 3 buttons and the presence of 6 indicator LEDs for ease of use.
• 3 operating modes that allow you to choose the best option for specific lighting conditions.
• 5 levels of dimming to adjust the brightness of the light.
• 6 timer levels for setting the lighting duration.
• Optional RF 2.4G wireless remote control with selectable single-zone or multi-zone dimming.
• Can be used as a 2.4G RF wireless remote control, can be combined with a wireless LED controller or a wireless LED dimmer (optional).
• Installation using self-adhesive ZM tape, which ensures speed and convenience of installation.
• Suitable for installation in kitchens, closets, stairwells, bedrooms, dressing rooms, living rooms, corridors, etc.

Features:

• Input voltage: 5-24VDC;
• Output voltage: 5-24VDC;
• Input current: 3.5A;
• Output current: 3A;
• Output power: 15-72W;
• Sensitivity angle: 120°;
• Input signal: PIR sensor + RF 2.4GHz;
• Control distance: 30m;
• Dimming level: 256 levels;
• Dimming range: 0-100%;
• Working temperature: -20 ~ + 55ºС;
• Size: L90xW48xH40;
• Degree of dust/moisture protection: IP20;
• Certificates: CE, EMC LVD, RED;

Warranty: 5 years.
