DEYA LED repeater on DIN rail EV4-D(black)

• EV4-D is a professional 4-channel constant voltage power amplifier designed to connect additional LED strips or modules to an existing controller.
• The device allows you to increase the total power of the LED system without losing control quality.

Application:

• Signal amplification for long LED strips;
• Increasing the power of LED systems;
• Connecting additional lighting sections;
• Use with dimmers, CCT, RGB and RGBW controllers;

Advantages:

• High output power up to 720W;
• Supports a wide voltage range of 12-36VDC;
• 4 independent channels with high current 5A each;
• Compatible with all types of PWM controllers;
• Compact design for DIN rail mounting;

Technical specifications:

• Input voltage: 12-36VDC;
• Output current: 5A per channel, maximum 20A;
• Output power: 240-720W (depending on voltage 12-36V);
• Input signal: PWM-CV;
• Output signal: PWM-CV;
• Number of channels: 4;
• Output power: 4 x (60-180)W;
• Output type: constant voltage;
• Operating temperature: -30~+55ºС;
• Dust/moisture protection level: IP20;

Warranty: 5 years.
