Description

Technical characteristics

Input voltage: 12-36VDC;
Input current: 20.5 A;
Input signal: PWM;
Output voltage: 4x (12-36)VDC;
Output current: 4CH, 5A/CH;
Output power: 4 x (60-180)W;
Output type: constant voltage;
Operating temperature: -30~+55ºС;
C degree of dust and moisture protection : IP20;
Warranty: 5 years.

DEYA LED repeater on DIN rail 12-24VDC, 5A*4CH (EV4-D)

Out of stock

SKU: 2198

$30/pcs.

Features

Product type	Repeater
Application	Dimmer, RGB, RGBW, CCT(Multiwhite)
Coating colour	White
IP rating	IP20
Mounting method	DIN rail
Body material	Plastic
Output Current	5 А
Output power	120 Вт
Input signal	PWM
Output signal	PWM
Control channels	4
Control type	PWM
Warranty	5 years
Dimensions	110 × 64 × 45
Length	110 mm
Width	64 mm
Height	45 mm
